Bicicleta Eléctrica de Montaña Mondraker LEVEL R

Mondraker Level R Chili Red – Aluminium Enduro e-MTB

The Level R Chili Red combines strength and performance thanks to its Stealth Evo aluminium frame and Bosch Performance Line CX Smart System motor with 800Wh battery.

The 170mm Zero Suspension system and Forward Geometry ensure control and stability on demanding terrain.

Equipped with RockShox ZEB Select 180mm fork, RockShox Vivid Coil shock and Sram Eagle T-Type 12-speed drivetrain.

Mullet e*thirteen Grappler Core wheels and Maxxis tyres deliver grip and reliability on every trail.

Technical specifications:

• Frame: Level 6061 Alloy Stealth Evo, Zero Suspension 170mm, Forward Geometry, removable internal battery, Boost 12x148mm axle, UDH, tapered head tube, Monobloc linkage, HHG internal routing, MAX bearings, 17mm axles
• Sizes: S (380mm), M (410mm), ML (435mm), L (460mm), XL (490mm)
• Shock: RockShox Vivid Coil base 205x65mm, rebound and preload, Trunnion mount, 30x8mm hardware
• Shock setup: Compression C26, rebound R23, coil springs per size (S 350 lbs, M 400 lbs, ML 450 lbs, L/XL 500 lbs)
• Fork: RockShox ZEB Select Charger RC 29, 180mm, Boost 15x110mm, 44mm offset, compression and rebound, air spring
• Headset: ONOFF ZS44/ZS56, sealed ACB bearings
• Stem: ONOFF S3 30mm 0º, 6061 aluminium
• Handlebar: ONOFF S3 1.0 6061 aluminium, 800mm, rise 25mm (38mm L/XL)
• Grips: ONOFF Desert Pro lock-on CNC 135mm (thicker on L/XL)
• Seatpost: ONOFF Pija, 31.6mm, internal routing, travel by size (S 115mm, M 135mm, ML 155mm, L/XL 185mm)
• Saddle: FIZIK Terra Aidon X5 145mm
• Brakes: Sram Maven Bronze, 4 pistons, HS2 rotors 220mm front / 200mm rear, metallic pads
• Brake levers: Sram Maven Bronze, SwingLink, reach adjust
• Wheels: e*thirteen Grappler Core, 6066 aluminium, hookless, tubeless ready, 30mm internal, 28 spokes, 29" front / 27.5" rear
• Spokes: e*thirteen triple butted, alloy nipples
• Hubs: e*thirteen Boost (15x110mm front, 12x148mm rear), fully machined, IS 6-bolt, HG freehub, 6º engagement
• Tyres: Maxxis Assegai 29x2.6WT 3C MaxxGrip DD front, Minion DHR II 27.5x2.6WT 3C MaxxTerra DD rear
• Cranks: Race Face Aeffect e-bike 160mm
• Chainring: Sram X-Sync 2 Eagle 34T, T-Type, steel
• Chain: Sram 70 Eagle T-Type 12s
• Rear derailleur: Sram 90 Eagle T-Type 12s
• Shifters: Sram 90 Eagle T-Type 12s, single-click shifting
• Cassette: Sram XS-1270 10-52T 12s
• Weight without pedals: 26.7 kg
• Display: Purion 400 / Bosch Mini Remote / Bosch System Controller
• Motor: Bosch Performance Line CX Smart System (25 km/h)
• Battery: Bosch Powertube 800Wh

A strong and powerful aluminium e-MTB, ready for demanding enduro riding.
