Bicicleta de Carretera Eléctrica GAIN M10I 2026

Orbea Gain M10i: road e-performance with Dura-Ace Di2 and Mahle X20 motor

The Orbea Gain M10i is designed for seamless harmony between rider and bike. With the Mahle X20 system, it offers smooth, natural pedal assistance that enhances road cycling without compromising feel.

The monocoque OMR carbon frame features full internal cable routing, rear light integration (STVZO standard), and support for up to 700x35c tires. Its matching carbon fork includes a 12x100mm thru-axle and Flat Mount brake support.

Shimano Dura-Ace Di2 R9200 delivers top-tier electronic shifting with a 34x50T crankset, 11-30T cassette, and CN-9100 chain. Braking is handled by Shimano R9270 hydraulic disc brakes for maximum control.

42mm carbon tubeless wheels combined with Pirelli P ZERO™ Race X SmartEVO 700x30c tires ensure fast, efficient rolling with superb grip. The ergonomic OC Carbon cockpit uses the RP10-R handlebar and RP10 stem (-8°) for performance-oriented positioning.

The Mahle X20 hub motor is powered by the internal iX350 battery (353Wh), managed via the Mahle ONE Head Unit and Dual eShifter, with data shown on the Pulsar One display (ANT+ compatible). The charger supports up to 4A charging.

Technical features:

• Frame: Orbea Gain Carbon OMR, monocoque, ICR, integrated rear light (STVZO), 12x142mm axle, BB386 EVO
• Fork: Gain OMR Carbon, 700x35c max, Flat Mount, 12x100mm axle
• Headset: FSA 1-1/2" Integrated Aluminium Cup
• Battery: Mahle iX350 36V 353Wh
• Motor: Mahle X20 rear hub, ALC
• Display: Mahle Pulsar One monochrome ANT+ LEV
• Control Unit: Mahle ONE Head Unit + Dual eShifter
• Charger: Mahle Active Charger up to 4A
• Crankset: Shimano Dura-Ace R9200 34x50T
• Shifters: Shimano R9270
• Cassette: Shimano Dura-Ace R9200 11-30T 12-Speed
• Rear Derailleur: Shimano Dura-Ace Di2 R9250
• Front Derailleur: Shimano Dura-Ace Di2 R9250
• Chain: Shimano CN-9100
• Handlebar: OC RP10-R Carbon, Rise 15, Reach 70, Drop 125
• Stem: OC Road Performance RP10, -8°
• Brakes: Shimano R9270 Hydraulic Disc
• Wheels: Carbon 42 Tubeless, 21c internal width
• Tires: Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
• Axles: Orbea Thru Axle 12x100mm / 12x142mm M12x2 P1 Lite
• Seatpost: OC Performance XP10-S Carbon, 27.2mm, Setback 20
• Saddle: Fizik Vento Antares R1 Carbon Rail 140mm
• Lights: Front COB LED 60 lm, Rear COB LED 12 lm (STVZO)
• Bar Tape: Orbea Anti-Slippery / Shock Proof

A premium road eBike that integrates advanced electronics and drivetrain technology for demanding cyclists.
